A DFT-Based QSAR and Molecular Docking Studies on Potent Anti-Colon Cancer Activity of Pyrazole Derivatives

Table of contents

1. Introduction

ancer is not a contagious neither infectious disease, but it has become a second leading cause of death worldwide and travels from one end to the other via bloodstream within the body system 1,2 . It can be caused by both external and internal factors, e.g. tobacco, infectious organisms, chemicals, and radiation are for outside while inherited mutations, hormones, and immune conditions for internal factor. Moreover, all of these factors may work together or in series to start or enhance carcinogenesis 3 . The cure for cancer remain surgery, chemotherapy and radiation therapy and adult, as well as, children can be affected. However, cases of children having cancer are limited 4 .

Colon cancer as a worldwide known health problem forays more than a million people every year, which has been the cause of death to over 600,000 people 5 . It is found to be the usual cause of death in comparison to other types of cancer that exist 6,7 . Several features that may cause an increment in colon cancer risks comprise diet, diabetes, aging, obesity, genomic instability, etc. Over the last half-century, the United States Food and Drug Administration (USFDA) has approved more than one hundred drugs for clinical treatment of cancers. Nevertheless the search for new and/or improved chemical compounds as potential anticancer agents continues with the hope that better efficacy and more manageable adverse side effects of pharmaceutical drugs may be achieved. Molecular modeling, screening and mimicking of natural compound derivatives have been among several drug discovery approaches to rationally design and modified structures that may confer a better therapeutic index 8 or that can cure cancer in the human race 9 .

Among such compounds are pyrazole and its derivatives, pyrazoles are class of heterocyclic compounds used for the development of drugs, and they have attracted the attention of several researchers due to their extensive biotic actions such as anticancer 10 , antifungal 11 , antiviral 12 , antiinflammatory 14,15 . More so, pyrazole derivatives such as Pyrazolopyrimidine and pyrazolo [4,3-d]pyrimdin-7-one perform some pharmacological activities which can never be put aside in the medical world, for example as antihypertensive 15 , antiviral 16,17 , tuberculostatic 18 , herbicidal agents 19 , antileishmanial 20 and treatment of heart diseases 21 . Therefore, the structural features of the Pyrazoles have been recognized as vital parameters due to their bioactivity as therapeutic aids. Several pyrazoles have been commercialized such as omeprazole, Albendazole, mebendazole, candesartan, telmisartan, astemizole [22][23][24] .

Quantitative Structural Activity Relationship (QSAR) as a statistical model embroils the relationship between physicochemical parameters of a chemical compound to its biological activity 25 . It has attracted vast usefulness for linking molecular evidence with biotic activities and many other physicochemical properties as well as its helpfulness for drug design, discovery, and development 26 . QSAR helps in the prediction of toxicity of materials in bulk system, for instance, drug-like compounds and are very useful in case of the classic chemicals [27][28][29][30] .

The use of molecular descriptors calculated from quantum chemical methods for development of QSAR models has been described to be sufficient for generating comprehensive QSAR. Thus the use of quantum chemical descriptors has countless potential [31][32][33][34] .

Molecular docking studies divulge information on the interaction between the drug-like compound known as a ligand and an enzyme/receptor through recognizing the active positions within the enzyme along with the binding energy calculation 34 . In molecular docking, scoring is a statistical way of predicting the strength of the interactions which are non-covalent in between a ligand and a receptor. Therefore, the calculations of interaction energy can be offered in the form of "dock score" 35 .

Consequently, in this research, twenty pyrazole derivatives with known anti-colon cancer activities 21 as displayed in Figure 1 were optimized using Density Functional Theory (DFT) method so as to obtain molecular descriptors for the compounds. These , b). Thus, the major objectives of this work are: (i) to calculate molecular descriptors with the use of quantum chemical method via Density Functional Theory (DFT), (ii) to develop QSAR model which probe into biological activity of the studied compounds, and (iii) to calculate the free energy of interactions (binding affinity, Î?"G) of the ligand with the receptor in the binding site through molecular docking.

Figure 1: The schematic structures of the pyrazole derivatives, the compounds were numbered as used in [20] II.

2. Computational Details a) Ligand optimization and molecular descriptors

The equilibrium geometries for the twenty optimized at Density Functional Theory (DFT). The use of DFT method entails three-parameter density functional, which comprises Becke's gradient exchange correction 37 and the Lee, Yang, Parr correlation functional (i.e., B3LYP) 38 . The accuracy of DFT calculations depends on the particular functional chosen and basis sets. However, 6-31G** basis set has been found to be appropriate for the confirmation search and calculation of drug-like compounds 39 . Therefore 6-31G** basis set was used in this work. Also, the optimized compounds were used to calculate molecular parameters/descriptors that described the bioactivity (IC 50 ) of the compounds. The optimized molecular structures were used for the docking study to estimate the binding affinity of the compounds to the colon cancer cell line, HT29 receptor (PDB ID: 2N8A). The optimization of the compounds was carried out using quantum chemical software Spartan '14 by wavefunctionInc 40 .

(S = 1/?) eV -1 Electro negativity [µ = 1/2 (E HOMO -E LUMO )] eV Nucleophilicity (? = µ 2 /2?) eV DM P HOMO LUMO SE (N+N)/2 BD ? S µ ?

3. b) Data processing and QSAR modeling

Furthermore, the chosen calculated parameters were engaged to develop quantitative structure-activity relationship (QSAR) model to link the bioactivity to the calculated molecular descriptors obtained from the studied compounds 41 . This was achieved using multiple linear regression (MLR) method which is a recurrent statistical technique used in developing QSAR model. MLR and correlation analyses were carried out by the statistics software SPSS 13.0 version. Before MLR analysis, the person correlation table was used to examine collinearity among the descriptors (r > 0.90). The descriptors with higher correlation with the dependent variable (IC 50 ] were retained, and the others were removed from the descriptor data matrix. The remaining descriptors were used to construct the MLR model, by the stepwise method. Moreover, the QSAR model was validated using some statistical equations such as cross validation (R 2 ) and adjusted R 2 . Cross validation is a mathematical method which oversees the reliability of QSAR model that can be used for a set of facts as shown in equation 1.

CV. R 2 = 1 ? ?(? obs ?? cal ) 2 ?(? obs ?? obs ) 2 (1)

The adjusted R 2 could be calculated using equation ( 2)

R a 2 = (N?I)×R 2 ?P N?P?1 (2)

where N is number of observations (compounds), p is number of descriptors, Also, for a good model, the standard error of estimate (s) of a set of data should be low, and this is defined as follows:

?? = ? ?(?? ?????? ??? ?????? ) 2 ??????1 (3)

To judge the overall significance of the regression coefficients, the variance ratio (F) which is the ration of regression mean square to deviations mean square can be defined as follows:

The F value has two degrees of freedom: p, N ? p ? 1. The computed F value of a model should be significant at p < 0.05; thus for overall significance of the regression coefficients, the F value should be high.

4. c) Molecular Docking and binding affinity

The downloaded HT29 receptor (PDB ID: 2N8A 42 ) from protein data bank was treated i.e., removal of water molecules, ligand, and cofactors from the receptor with the use of discovery studio. Then, both the receptor and ligand were converted to the acceptable format (pdbqt) for AutoDockvina programme. The grid dimension used for all the 2N8A protein was are 50 × 40 ×40 Å (grid size) with point separated by 1.000 Å (grid-point spacing). The docking was done using autodock vina which was inspired by Darwinian evolution theory to be iterative optimization method 43 which involves search Algorithm. At the completion of the docking runs, ligand showing different conformations known as Binding modes were obtained with their respective binding affinity. The stable pattern was assumed to be the one with the lowest binding affinity and was taken for post-docking analysis using Edupymol version 1.7.4.4.

5. III.

Result and Discussion a) QSAR modeling The molecular descriptors calculated for the twenty pyrazole compounds served as independent variables, while the observed inhibitory actions (IC 50, µM) against cancer cells line as the dependent variable in the development of QSAR model via multiple linear regression (MLR). These molecular descriptors used for QSAR model were displayed in Tables 2 and 3. In QSAR study, the quality of a model is evaluated by its fitting and prediction abilities; however, for a model to be acceptable, its predictability power is of paramount important. Therefore, Pearson's matrix was used for the selection of suitable descriptors for the QSAR study (Table 4). The selected descriptors were used to build a linear QSAR model to understand how multiple linear regression (MLR) equations can explain the structural key points correlating to differential behavior in bioactivity against colon cancer cell (HT29) as shown in equation 4. This model was validated statistically by using the squared fitting factor (R 2 ), cross validation (CV.R 2 ), adjusted fitting factor ( adj R 2 ) and variation ratio (F). The developed model was very robust in predicting satisfactory the experimental values. The high values of F, R 2 , CV.R 2 and adj R 2 as shown in Table 5 indicated that the models are statistically acceptable and also have good external predictability 44,45 . The calculated R 2 is 0.9564; this revealed a reasonable fitness, and it also uncovered the efficiency of the model as displayed in equation 4. The value for CV.R 2 was calculated to be 0.9542 which is greater than 0.5 (standard) 46 , and this showed the reliability and acceptability of the model as well as the adjusted R 2 with 0.9247 which was greater than 0.6 (Table 5)

IC

The QSAR model contained eight descriptors in different combinations; each descriptor with either positive or negative coefficient attached to it. However, the magnitudes of the coefficients as well as, the values of descriptors have significant roles in deciding the overall biological activity of the molecule. The descriptors with negative coefficients in the model were very significant because they contributed towards increasing the value of the biological activity of anti-colon cancer agents. Therefore, the descriptors with a negative coefficients were most significant followed by descriptors with low weight positive coefficients and lastly the parameters with high weight positive coefficients. The predicted anti-colon cancer activity of the ligands using the QSAR model as well as deviation from the experimental values was displayed in Table 6 and graphically presented in Figures 2 and 3. Observed IC 50 (?M)

Predicted IC 50 (?M) The molecular docking studies were performed on the twenty pyrazole derivatives together with colon cancer cells line (PDB ID: 2N8A) 42 obtained from protein data bank. This was achieved with the use of several software such as Discovery studio, Autodock tool, Autodock vina and Pymol as post-dock software. Docking of each compound was carried using autodock vina and conformations obtained varies in number but ranged from 8 -15 conformations for compounds 3a-19b. The structure with lowest binding energy (i.e., highest negative free energy of binding, Î?"G) in each docking simulation was taken to be most stable and analyzed for detailed interactions using Discovery Studio Visualizer4.0 software. Docking simulations can be understood by comparing the values of the free energy of binding (Gibbs energy, Î?"G) of the ligands to the protein receptor. Î?"G is an indicator to show the stability interaction between ligand and receptor, and it can be used to explain the strength of binding energies of different docking conformation 47,48 .

The poses of the lowest conformation of each ligand were examined based on Î?"G, and interaction of the ligand with the 2N8A protein structure in ligandreceptor complex. The free binding energy (Î?"G) calculated for the docked twenty pyrazole derivatives ranged from -6.10 kcal/mol (ligand 7a) to -8.20 kcal/mol (ligand 19b) as displayed in Table 7. The interaction of ligand with the 2N8A protein structure was discussed by of H-bonding between the ligand and the receptor molecule as shown in Figure 4. Analysis of the ligandreceptor complex showed that H-bonds played a prominent role in the binding and posed stability of the ligand in the ligand-receptor complex; thus affect the potency/function of biological molecules. The number of H-bonds present in the ligand-protein complex as well as H-bonds distances was shown in Table 7 IV.

6. Conclusion

In this study, the quantum chemical method via density functional theory (DFT) method was used for calculation of molecular descriptors relating to the anticancer activity of pyrazole derivatives. The QSAR analysis revealed the efficiency of the model developed using multiple linear regression (MLR), and that the QSAR model replicated the observed bioactivities of the studied compounds against colon cancer cells line (ID: 2N8A). Furthermore, the simulated molecular docking predicted stable conformations of the drug-like molecules (Pyrazolederiatives) in the active gouge of the receptor. Also, the binding energy as well as, nature of electrostatic interactions of the ligands in the ligandreceptor complexes were obtained for the twenty compounds.

Figure 1. compounds are 4 -
4amino-3-(4-chlorophenyl)-1Hpyrazolyl-5-yl-(3,5-dimethyl-1Hpyrazol-1 yl) derivatives) methanone (3a, b), 2-{[4-amino-3-(4-chlorophenyl)-1Hpyrazol-5-yl]carbonyl}-5-methyl-2,4-dihydro-3H-pyrazol-3-one (4), 1-{[4-amino-3-(4-chlorophenyl-1H-pyrazol-5yl]carbonyl} pyrazolidine-3,5-dione (5), 3-(4-chlorophenyl)-5-(1,3,4-oxa/thiadiazol-2yl)-1H-pyrazol-4-amine (7a, b), 6-amino-3-(4-chlorophenyl)-5-methyl-1,6-dihydro-7H-pyrazolo-[4,3-d]pyrimidin-7-one (9), 4amino-3-(4-chlorophenyl)-N'-[arylmethylidene]-1Hpyrazole-5-carbhydrazide (10 a-d), 3-(4-chlorophenyl)-5methyl-1,6-dihydro-7H-pyrazolo[4,3-d]pyrimidine-7-one (12), 7-chloropyrazolo [4,3-d] pyrimidine (13), 3-(4-chlorophenyl)-7-(3,6-dihydro-2H-pyran-4-yl)-5-methyl-1H-pyrazolo[4,3-d]pyrimidine (14),7-(4-chlorophenyl)-5methyl -9H-pyrazolo[3,4-e]tetrazolo[1,5-c]pyrimidine (15), Ethyl{[3-(4-chlorophenyl)-5-methyl-1H-pyrazolo [4,3-d]pyrimidine-7-yl]oxy} acetate (16), 6-amino-3-(4-chlorophenyl)-5-thioxo-1,4,5,6-tetrahydro-7Hpyrazolo[4,3-d] pyrimidin-7-one (17), 2-{[4-amino-3-(4-chlorophenyl)-1H-pyrazol-5-yl] carbonyl} hydrazinecarbothioamide (18), 4-amino-3-(4-chlorophenyl)-N'-(4-methyl/ or 4-phenyl-1,3-thiazol-2yl)-1H-pyrazole-5-carbohydrazide (19a
Figure 2.
Bond length between two Nitrogen atoms of the pyrazole ring Bond length between Nitrogen and the hydrogen atom of pyrazole ring Natural charge population on Hydrogen atoms of the pyrazole ring Hydrogen bond
Figure 3.
Based QSAR and Molecular Docking Studies on Potent Anti-Colon Cancer Activity of Pyrazole Derivatives pyrazole derivatives as reflected in this paper were ?? = ???? ?????? ??"®obs ? 2 ?? ???? ?????? ??? ?????? ? 2 ?? ??? ?1
Figure 4.
50 = -2677.65 -38.6214(BG) + 0.864947(DM) + 257.863(NNBL) + 2353.57(NHBL) -190.240(HHET4r) -39.6798(HOMO) + 37.8067(LUMO) + 0.0699416(PSA)
Figure 5. Table 1 :
1
Descriptors Symbol Abbreviation
Quantum Molecular dipole moment
chemical Molecular polarizability
descriptors Highest occupied molecular orbital, eV
Lowest unoccupied molecular orbital, eV
Solvation energy (au)
Figure 6. Table 2 :
2
MOL HOMO LUMO BG DM SE (au) (N+N)/2 Het ? µ ?
3a -5.54 -1.66 3.98 5.26 -0.01389 -0.379 3.600 -1.940 0.5227
3b -5.66 -1.85 3.81 3.33 -0.01208 -0.379 3.755 -1.905 0.4832
4 -5.87 -1.60 4.27 6.35 -0.02134 -0.353 3.735 -2.135 0.6102
5 -6.58 -1.94 4.64 2.54 -0.03482 -0.355 4.260 -2.455 0.7074
7a -5.74 -1.41 4.33 3.51 -0.02187 -0.398 3.575 -2.165 0.6556
7b -5.66 -1.80 3.86 3.76 -0.01747 -0.399 3.730 -1.930 0.4993
9 -5.96 -1.36 4.60 4.23 -0.01815 -0.405 3.660 -2.300 0.7227
10a -5.84 -0.82 5.02 5.19 -0.01575 -0.368 3.330 -2.510 0.9460
10b -5.84 -1.65 4.33 1.68 -0.01442 -0.368 3.815 -2.165 0.6143
10c -6.07 -1.80 4.27 1.81 -0.01671 -0.377 3.935 -2.135 0.5792
10d -5.56 -1.44 4.12 2.91 -0.01841 -0.368 3.500 -3.128 1.3973
12 -5.99 -1.31 4.68 4.11 -0.01977 -0.401 3.650 -2.340 0.7501
13 -6.23 -2.09 4.14 2.26 -0.01402 -0.413 4.160 -2.070 0.5150
14 -5.91 -2.09 3.82 4.67 -0.01784 -0.427 4.000 -1.910 0.4560
15 -5.91 -1.99 4.39 0.76 -0.01789 -0.424 4.185 -2.195 0.5756
16 -5.88 -1.45 4.43 6.68 -0.01861 -0.418 3.665 -2.215 0.6693
17 -6.18 -1.89 4.29 3.02 -0.02548 -0.391 4.035 -2.145 0.5701
18 -5.79 -1.41 4.38 4.84 -0.03355 -0.396 3.600 -2.190 0.6661
19a -5.73 -1.24 4.49 4.68 -0.02043 -0.372 3.485 -2.245 0.7231
19b -5.70 -1.30 4.40 4.39 -0.02085 -0.371 3.485 -2.200 0.6914
Figure 7. Table 3 :
3
H HET4r HBD HBA 0.294 2 6 0.294 2 6 0.296 3 7 0.300 3 8 0.285 2 6 0.282 2 6 0.292 2 5 0.292 3 6 0.294 3 6 0.295 3 6 0.293 3 7 0.294 1 4 0.292 1 4 0.277 1 5 0.297 1 6 0.287 1 6 0.300 3 7 0.287 5 8 0.292 3 7 0.293 3 7
NHBL 1.012 1.011 1.010 1.010 1.008 1.008 1.008 1.010 1.010 1.010 1.010 1.008 1.008 1.006 1.008 1.007 1.009 1.009 1.009 1.009 Year 2018
NNBL 1.322 1.322 1.320 1.329 1.333 1.334 1.345 1.329 1.334 1.336 1.333 1.345 1.354 1.352 1.352 1.351 1.339 1.335 1.327 1.327 13
Log P PSA Pol 0.07 63.211 64.57 -0.06 63.228 65.69 -1.01 85.752 63.71 -1.52 100.075 62.61 0.26 74.597 58.95 0.83 64.537 59.82 -0.15 72.744 60.29 0.60 88.836 66.90 1.62 79.201 66.94 2.02 79.118 67.71 1.34 86.232 68.82 0.10 56.316 59.33 1.55 37.704 59.98 1.67 42.724 65.70 1.83 68.584 60.37 0.76 64.473 64.95 0.15 74.925 60.23 -0.96 106.292 61.96 0.09 89.093 65.42 1.49 88.388 70.75 Volume XVIII Issue II Version I
Ova 1.48 1.51 1.48 1.46 1.39 1.40 1.42 1.55 1.45 1.55 1.57 1.39 1.40 1.47 1.40 1.52 1.41 1.49 1.53 1.59 ( D D D D )
MOL MW Vol 3a 315.764 297.32 3b 350.209 310.90 4 317.736 287.79 5 319.708 275.32 7a 261.672 229.28 7b 277.739 238.68 9 275.699 246.62 10a 341.802 329.28 10b 357.776 327.84 10c 374.231 337.13 10d 369.812 350.35 12 260.684 235.01 13 279.130 241.38 14 326.787 311.07 15 285.698 246.93 16 332.747 303.52 17 293.738 244.92 18 310.679 266.54 19a 348.818 309.47 19b 410.889 374.88 Global Journal of Medical Research
Figure 8. Table 4 :
4
HT29 HOMO LUMO BG DM SE N+N/2HET CP CH GN MW VOL OVA LOGP PSA POL NNBL NHBL HHET4r HBD HBA HT29 1.000 HOMO -0.009 1.000 LUMO 0.306 0.476 1.000 BG 0.334 -0.349 0.655 1.000 DM 0.280 0.520 0.506 0.102 1.000 SE -0.370 0.372 -0.028 -0.342 -0.064 1.000 N+N/2HET 0.274 0.152 0.320 0.219 0.060 -0.173 1.000 CP -0.434 0.005 -0.448 -0.472 0.092 0.229 -0.343 1.000 CH -0.191 -0.828 -0.888 -0.235 -0.596 -0.177 -0.284 0.283 1.000 GN 0.423 0.230 0.567 0.397 0.039 -0.111 0.356 -0.970 -0.482 1.000 MW 0.283 0.285 0.195 -0.044 0.044 0.125 0.533 -0.225 -0.274 0.284 1.000 VOL 0.295 0.365 0.272 -0.027 0.130 0.233 0.499 -0.272 -0.365 0.355 0.973 1.000 OVALITY 0.456 0.419 0.414 0.078 0.303 0.061 0.501 -0.349 -0.484 0.442 0.913 0.921 1.000 LOGP -0.292 0.049 -0.199 -0.266 -0.375 0.587 -0.434 0.018 0.101 0.015 0.257 0.299 0.152 1.000 PSA 0.524 0.033 0.483 0.482 0.081 -0.631 0.672 -0.459 -0.325 0.439 0.392 0.311 0.457 -0.488 1.000 POL 0.288 0.372 0.258 -0.047 0.128 0.240 0.494 -0.262 -0.360 0.347 0.973 1.000 0.918 0.304 0.300 1.000 NNBL -0.095 -0.463 -0.331 0.031 -0.245 0.078 -0.861 0.044 0.454 -0.137 -0.422 -0.394 -0.446 0.488 -0.580 -0.395 1.000 NHBL 0.240 0.221 0.135 -0.013 -0.074 0.098 0.787 -0.137 -0.202 0.174 0.402 0.380 0.386 -0.334 0.435 0.381 -0.802 1.000 HHET4r 0.088 -0.447 -0.027 0.374 -0.354 -0.135 0.527 -0.289 0.251 0.164 0.143 0.058 0.059 -0.260 0.347 0.050 -0.293 0.606 1.000 HBD 0.565 0.168 0.346 0.219 0.066 -0.541 0.655 -0.273 -0.308 0.294 0.417 0.328 0.445 -0.432 0.873 0.323 -0.600 0.501 0.234 1.000 HBA 0.416 0.048 0.131 0.097 0.096 -0.658 0.579 -0.263 -0.109 0.241 0.422 0.308 0.442 -0.451 0.861 0.305 -0.583 0.410 0.267 0.787 1.000
Figure 9. Table 5 :
5
N p R 2 CV.R 2 R 2 adj s F
20 8 0.9564 0.9542 0.9247 0.4141 30.168
Figure 10. Table 6 :
6
Comp Observed Predicted Residual Comp Observed Predicted Residual
3A 1.45 1.45 -0.00 10D 3.57 3.05 0.52
3B 1.10 1.57 -0.47 12 0.78 0.54 0.24
4 2.78 2.53 0.25 13 1.52 1.23 0.29
5 2.99 2.82 0.17 14 0.88 0.96 -0.08
7A 0.28 -0.26 0.54 15 0.29 0.70 -0.41
7B 0.20 0.31 -0.11 16 3.88 3.86 0.02
9 1.77 2.19 -0.42 17 1.33 1.24 0.09
10A 4.08 4.16 -0.08 18 5.59 5.65 -0.06
10B 2.10 2.18 -0.08 19A 0.42 1.09 -0.67
10C 2.92 2.83 0.09 19B 0.78 0.62 0.16
Figure 11. Table 7 :
7
Year 2018
17
1
