Characteristics of Craniofacial Complex For class II Division 1 Malocclusion in Saudi Subjects with Permanent Dentition

Table of contents

1. Introduction

lass II malocclusion is a frequently seen disharmony that has been studied in many different populations [1][2][3][4] because excessive overjet is easily recognized, class II division 1 malocclusion is of a greater concern for both patients and parents.

A review of literature shows that class II malocclusion has been evaluated in all three dimensions of space. In general, these studies have compared the craniofacial morphology of patients with class II malocclusion with class I control subjects.

Studies evaluating maxillary and mandibular skeletal and dental positions and vertical components of class II patients have reported conflicting results from both cross-sectional and longitudinal studies. No common results have been found regarding cranial base configuration.

The class II division 1 malocclusion is the most frequent in particular clinics, [5] caused in most times, by a retrognathic mandible [5,6] McNamara indicated that retrusion of the mandible is the most commonly occurring factor contributing to class II malocclusion, and the average position of the maxilla was found to be neutral in relation to cranial base structures. [7] Although many studies have investigated class II malocclusion characteristics, [7,8,9,10] , few have studied the characteristic of skeletal II malocclusion in specific ethnic groups. [5,11,12] .

Therefore, in order to provide more specific information regarding this type of malocclusion in Saudi subjects, this comparative Cephalometric study was undertaken.

The objectives of this comparative Cephalometric study were to:

1. Determine the specific Cephalometric features of class II division 1 malocclusion in adult Saudi subjects that had not been previously submitted to any orthodontic treatment. 2. Compare the changes in the dentofacial structure in untreated class II division 1 malocclusion and normal occlusion class I individuals. 3. Evaluation of the following features of the jaws was made: angular and linear sagittal relation between maxilla and mandible and related to the cranial base; geometric proportion between maxilla and mandible; craniofacial growth pattern and position of maxillary and mandibular incisors, presence of differences between genders.

2. II.

3. Materials and Methods

Careful selection was made from the files of orthodontics clinics in King Abdul-Aziz Medical City, National Guard Health Affairs, Riyadh, Kingdom of Saudi Arabia, from January 2013 to June 2014. A minimum sample size of 21 per group (total 42) will have 80% power to detect a difference in means of 1 0 (Change in the skeletal ANB angle), (Cozza P et al, 2006) [13] assuming that the common standard deviation is 1.25 0 (Sayin & Turkkaharaman, 2005) [14] , using a two group t-test with a 0.05 one sided significance.

The radiographic lateral cephalograms used were taken according to the conventional norms.

All cephalograms were taken by the same radiographic apparatus: planmecapromax 3Ds/3D Planmecaoy/Asentajankatu6/00800 Helsinki/Finland. Cephalometric Landmarks were marked and digitized by one author to avoid interobserver variability angular and linear variables were established and measured by: Vistadent ? At software (GAC int. Inc. The reference points, planes and angles used in current study were defined according To Bjork, Riolo et al [15,16] The causal error was calculated according to Dahlberg's formula [17] ME=

? d 2 2n

Where d is the difference between two registration.

n is the number of duplicate registration and the systematic error with dependent tests, for P<0.05

The error of the method of cephalometric measurement ranged between 0.16mm and 0.41mm for linear measurements, and between 0.18 degree and 0.46 degree for angular measurements. (Allowable inter-and intra-investigator error were 0.5 mm and 0.5 degree) c) Statistical Analysis Descriptive statistic was calculated for all measurements in both groups including the mean, standard deviation, and minimum and maximum values for each parameter. [18] All the statistical analysis were performed by using SPSS-V15 (SPSS Inc., Chicago-ILL).

Anderson-Darling normally tests were performed to check the distribution of data, parametric (two-sample-t-test) or non parametric (Mann-Whitney U test), were used as appropriate to detect significant differences between the two groups with the level significance at 0.05, p<0.05

The comparison between genders in class II division 1 used the same statistical test.

Statistically significant values were considered if p<0.05

There was no difference in the mean position of the maxilla-(SNA) between the two groups, and the class II appeared to be the result of more recessive (SNB) and shorter mandible (Go-Me).

(These results were also supported by maxillary and mandibular skeletal measurements that were not sella-nasion based).

This was accompanied by an increased mandibular plane angle (Go-Gn/SN) but no increase in anterior facial height. The increased mandibular plane angle appeared to be the result of a reduced ramus height with a reduced posterior facial height in the class II division1 group.

In class II division I patients, the maxillary incisors were buccally inclined (upper incisor-NA) and the mandibular incisors were buccallyinclined and more protrusive (Lower incisor-NB), the overjet was significantly greater in class II division 1 group.

The cranial base angle (NS^Ar) was significantly greater in class II division 1 subjects, and the posterior cranial length (S-Ar) was significantly shorter in class II division 1 group.

The (ANB) angle was significantly greater in class II division 1 subjects.

The Bjork sum (angleNS^Ar, SAr^Go ,ArGo^me)was significantly greater in class II division 1 subjects.

Angle retuded chin is indicated by small (SN^Pog) angle in class II division 1 subjects. IV.

4. Discussion

Class II malocclusion has been evaluated in numerous studies. [19,20,21]. These studies have reported conflicting results about the features of class II malocclusion both in the anteroposterior and vertical dimensions.

Class II malocclusion may results from numerous combination of skeletal and dental components [22] This was also true for our sample because wide variations were observed for almost all measurements of the class II division 1 patients (Table 1, 2).

Fushima et al [21] reported aretruded and smaller mandible in adult females with class II division 1 malocclusion. In another study of adult patients, Gilmore [23] reported that the mandible was shorter in dental class II division 1 patients. Because our results are consistent with previous studies on adults, we suggest that the majority of class II division 1 patients have a normally positioned maxilla but a smaller and more retruded mandible when compared with class I patients.

Conflicting results of studies regarding anteroposterior positions of maxilla and mandible in The sagittal position of the mandible (SNB) presented that it was retracted in relation to the cranial base. The effective length (Go-Me) showed a small sized mandible. These results are in agreement with other studies in the literature. [6,7,24,25,26,27] demonstrating that the mandible presents great participation in this type of malocclusion.

These cephalometric results justify the mandibular advancement for correction of the class II malocclusion in great part of the cases [28,29] Our results indicated that the class II division 1 patients show an increased mandibular plan angle (NS^Go Me) but no increase in anterior facial height (ANS-Me).

The increased mandibular plan appeared to be the result of reduced ramus height. In accordance with our results. Fushima et al [21] growing class II patients may be attributed to the individual differences in skeletal growth rates of these patients.

The sagittal position of the maxilla (SNA) in class II division 1 patients was normally positioned similar to the normal class I group, with a well-positioned maxilla in relation to the cranial base, corroborating previous studies [6,7,18,24,25] rotation of the mandible in class II division 1 patients. Bjork and Skieller [30] reported that the intensity of the Condylar growth was strongly correlated with the rotation of the mandible.

Sinclair and Little [31] reported that the degree of vertical mandibular growth was closely correlated with the total amount of condylar growth.

Discrepancy in the posterior face height especially in ramus height may indicate decreased condylar growth in class II division 1 patients. Histological and implant studies [32,33,34] have demonstrated that growth in mandibular length occurs primarily at the condyle, the decreased mandibular length found in class II division 1 patient also supports our findings.

The maxillary incisors presented buccal inclination (UI.NA) in class II division 1 subjects. That findings are in consonance with the results of previous studies [6,7,18,35] .

The position of maxillary incisors presented protrusion in relation to the cranial base (UI^SN) in The angular measurement for the mandibular incisors (LI-NB) presented statistically significant differences, showing mandibular incisors strongly bucally inclined.

The results for the linear position of mandibular incisors (LI-NB) showed protrusion in relation to their apical base, indicating dento-alveolar compensation for the skeletal discrepancy.

The craniofacial growth pattern presented a vertical tendency in class II division 1 subjects, (Bjorksum). These finding are uniform to those mentioned in most studies [7,8,12], however some authors found contrasting results [9,37] The cranial base angle (NS^Ar) was significantly greater in class II division 1 subjects. The larger cranial base angle in class II subjects might explain the distal positioning of the mandible.

The sagittal discrepancy of the skeletal base angle (ANB) presented an increase in this angle in class II division 1 subjects when compared to the normal occlusion subjects corresponding with other studies [5,11] Hopkin et al [38] stated that the cranial base configuration was an etiological factor in determining anteroposterior male relationships of the jaws. However a review of the literarure indicated no common results concerning cranial base configurations of class II patients.

Dhopatkar et al [39] has suggested that cranial base morphology was more important in establishment of mal occlusion when there was a significant skeletal discrepancy. This is also acceptable for our study because our class II patient have significantly greater over jet and ANB angle than class I subjects.

bigger facial dimensions than females with the resemblance in the geometric proportions and craniofacial morphology. class II subjects.This results diverges from studies in the literature [14 ,36,] V.

5. Conclusion

According to the methodology used, the cephalometric characterizations of Saudi subjects presenting class II division 1 malocclusion were the following:

The maxilla was well positioned in relation to the cranial base and in normal size.

The mandible was smaller in size, posteriorly positioned ((retracted)) and rotated posteriorly when compared with class I subjects.

The geometric proportion between the apical base presented a small mandible and a normal size maxilla.

The craniofacial growth pattern showed a vertical tendency.

The maxillary and mandibular incisors were bucally inclined and protrusively positioned in relation to skeletal base.

Gender comparison revealed that there was statistical difference in linear measurements.

However, there was no difference in angular measurements. This may indicate that males have

Figure 1.
Forty-nine (49) Saudi individuals having a class II division 1 (23 females and 26 males) aged 18-28 years were evaluated and compared with forty-five (45) Saudi Azzam Al -Jundi ? & Hicham Riba ? individuals having normal occlusion class I pattern (21 females and 24 males) aged 18-28 years. Selection criteria for class IIdivision1sample were: ANB angle ? 4?; Over jet ? 4 mm; Bilateral class II molar in centric occlusion; Permanent dentition, no missing teeth, (except third molars); Convex facial profile; No previous orthodontic treatment; No cleft lip/palate and/or other craniofacial syndromes All selected subjects are Saudi descent. Selection criteria for the class I sample were: ANB angle ? 4?; Over jet ? 4 mm; Normal over bite; Bilateral class I molar and canine in centric occlusion; Permanent dentition, no missing teeth (except third molars); Well-aligned maxillary and mandibular arches with less than two mm crowding or spacing; Class I soft tissue profile; No previous orthodontics treatment. a) Determination of sample size
Figure 2.
Bohemia, NY) No cleft lip/palate and/or other craniofacial syndromes ; All selected subjects are Saudi descent; Cephalometric skeletal landmarks used in current study: Fig (1) N-S -ANS -PNS -A -B -Pog-Me-Ar-Go-Bo -Ao.
Figure 3. Figure 1 :
1Figure 1 : Cephalometric Skeletal Landmarks used in the Current Study Cephalometric dental and soft tissues landmarks used in the current study:Fig(2) UI-APUI -LI -APLI-Pog'-Li-LS -Sn -Pn.
Figure 4. Figure 2 :
2Figure 2 : Cephalometric Dental and Soft Tissue Landmarks used in the Current Study The linear measurements used in the current study: ( Fig 3) S-N, S-Ar, Ar-Go, Go-Me, S-Go, S-PNS, PNS-Go, N-Me, S-Gn, ANS-PNS, UI-NA, LINB, pog-NB LI-APog,Ls-ELine, Li-ELine , (B0 -A0) Wits Appraisal.
Figure 5. Table 1 :
1
2014
Year
Volume XIV Issue VI Version I
( ) J
Tables (1-4) show descriptive statistics and
comparison of cephalometric measurements between
two groups.
Class II, 1 Class I
Variable Pts N Mean SD Pts N Mean SD P
NS ^ GoMe 49 33.63 2. 78 45 31.00 3.39 0.00
Ns ^ PP 49 8.01 1.15 45 7.93 1.99 0.18
NSAr 49 125.91 2.91 45 123.95 2.33 0.00
SArGO 49 142.91 2.58 45 141.11 1.70 0.00
ArGoMe 49 133.08 3.45 45 129.72 4.59 0.00
Sum(Bjork) 49 400.01 4.07 45 396.58 5.91 0.00
NSPog 49 69.98 3.22 45 66.20 4.13 0.00
SNA 49 81.66 2.51 45 80.96 3.02 0.22
SNB 49 75.42 3.14 45 78.53 2.81 0.00
ANB 49 6.21 1.94 45 2.57 1.01 0.00
SNPog 49 78.04 2.84 45 82.39 2.57 0.00
NAPog 49 184.93 3.90 45 179.10 4.40 0.00
MM 49 28.57 2.92 45 25.84 3.12 0.00
UI ^ SN 49 109.63 4.58 45 102.49 4.45 0.00
UI ^ Spp 49 67.69 4.23 45 70.10 3.25 0.00
Figure 6. Table 3 :
3
Variable Sex No Min Max Mean SD P
N-S M 26 67.16 77.25 72.88 2.68 0.04
F 23 65.81 75.64 70.82 2.58
S-Ar M 26 28.68 39.82 33.76 2.93 0.08
F 23 29.15 37.61 32.30 2.49
Ar-Go M 26 46.50 56.62 51.22 2.80 0.34
F 23 45.83 55.15 50.48 2.57
Go-Me M 26 7.35 79.62 74.93 2.84 0.00
Figure 7. Table 2 :
2
Class II, division 1 Normal Occlusion
Variable No Mean SD No Mean SD P
N-S 49 72.49 2.70 45 73.11 3.82 0.12
S-Ar 49 33.07 2.80 45 36.25 2.82 0.00
Ar-Go 49 50.88 2.69 45 52.34 3.18 0.01
Go-Me 49 73.43 3.00 45 76.83 4.73 0.00
S-Go S-PNS 49 49 82.12 40.68 2.26 1.91 45 45 86.04 41.16 5.53 3.59 0.00 0.73 Volume Issue VI Version I
Figure 8. Table 4 :
4
PNS-GO M 26 37.46 45.15 41.87 2.15 0.04
F 23 36.85 44.67 40.71 1.79
2014
Year
Volume XIV Issue VI Version I
( ) J Variable Sex No Min Max Mean SD P
NS ^ GoMe M 26 27.68 38.65 33.73 2.99 0.70
F 23 26.94 37.16 33.53 2.58
Ns ^ PP M 26 6.35 10.05 8.21 1.14 0.29
F 23 5.65 9.26 7.79 1.15
NSAr M 26 120.95 131.61 125.99 2.65 0.85
F 23 119.95 131.46 125.83 3.24
SArGO M 26 138.26 147.16 143.30 2.48 0.92
F 23 136.26 145.03 142.46 2.68
ArGoMe M 26 125.54 138.74 132.92 3.70 0.93
F 23 128.15 139.25 133.25 3.23
Bjork Sum M 26 392.94 411.37 399.97 4.51 0.88
F 23 396.12 408.06 400.05 3.60
NSPog M 26 61.58 75.16 69.25 3.58 0.09
F 23 66.22 76.13 70.81 2.61
SNA M 26 77.82 86.94 81.81 2.50 0.66
F 23 76.65 87.61 81.49 2.58
SNB M 26 71.42 80.90 75.37 2.83 0.77
F 23 68.35 83.31 75.48 3.53
ANB M 26 4.21 10.01 6.43 1.37 0.33
F 23 .70 11.10 5.97 2.45
© 2014 Global Journals Inc. (US)

Appendix A

Appendix A.1

Appendix B

  1. A Bjork . Face in Profil. SvenskTandläkartidskrift. Berlingska Boktryckeriet Lund, 1949. 40.
  2. Facial growth in man, studied with the aid of metallic implants. A Bjork . ActaOdont Scand 1955. 13 p. .
  3. Variation in the growth pattern of the human mandible: Longitudinal radiographic study by the implant method. A Bjork . J Dent Res 1963. 42 p. .
  4. An investigation into the relationship between the cranial base angle and maloocusion. A Dhopatkar , S Bhatia , P Rock . Angle Orthod 2002. 72 p. .
  5. A comparison of craniofacial Class I and Class II growth patterns. A M Riesmeijer , B Prahl-Andersen , A K Mascarenhas , B H Joo , K W Vig . AM J Orthod Dentofacial Orhtop 2004. 125 p. .
  6. Facial development and tooth eruption. An implant study at the age of puberty. Bjork A , V Skieller . Am J Orthod 1972. 62 p. .
  7. Prevalence and Characteristics of malocclusion among senior high school students in up-state New York. D B Ast , J P Carlos , D C Cons . AmJ Orthod 1965. 51 p. .
  8. P Craniofacial morphology of Japanese girls with class II division 1 malocclusion. Deguchi T Ishiin , N Hunt . J Orthod 2001. 28 p. .
  9. A study of postnatal growth of the human mandible. D H Enlow , D B Harris . Am J Orthod 1964. 50 p. .
  10. The cranial base as an etiological factor in malocclusion. G B Hopkin , Wjb Houston , G A James . Angle Orhtod 1968. 38 p. .
  11. Statistical methods for medical and biological students, G Dahlberg . 1940. New York: Interscience.
  12. Occlusal changes from adolescence to adulthood in untreated patients with Class II division 1 deep bite malocclusion. I Feldmann , F Lundstrom , Pecks . Angle Orthod 1999. 69 (1) p. .
  13. Functional appliance therapy with Bionator SeminOrhtod, I Rudzki-Janson , R Noachtar . 1998. 4 p. .
  14. Components of Class II malocclusion in children 8-10 years of age. J A Mcnamarajr . Angle Orthod 1981. 51 (3) p. .
  15. A method of Cephalometric evaluation. J A Mcnamarajr . Am J Orthod 1984. 86 (6) p. .
  16. A Longitudinal study of condylar growth and mandibular rotation in untreated subjects with Class II malocclusion. J Kim , L I Nielsen . Angle Orthod 2002. 72 p. .
  17. Functional appliances: a mortgage on mandibular position. J R Johnston . AustOrhtod J 1996. 14 (3) p. .
  18. Longitudinal mandibular growth in children with tantanium implants. J R Malhews , W H Ware . Am J Orthod 1978. 74 p. .
  19. Significance of the cant of the posterior occlusal plane in class II division 1 malocclusion. K Fushima , Kitamuray , H Mita , S Sato , Y Suzuki , Y H Kim . Eur J Orthod 1996. 18 p. .
  20. An atlas of craniofacial growth: Cephalometirc standards from the University school growth study. Ann Arbor: Centre of human growth and developments, M L Riolo , R E Moyers , J A Mcnamara , Hunter Ws . 1974. University of Michigan.
  21. Dentofacial changes in untreated Class II division 1 students. N E Carter . Br J Orthod 1987. 14 (4) p. .
  22. Dento-skeletal components of Class II malocclusions for children with normal and retruded mandible. O A Sarhan , H A Hashim . J ClinPediat Dent 1994. 18 p. .
  23. Mandibukar changes produced by functional appliances in class II malocclusion: A systematic review. P Cozza , Baccettit , L Franchi , L Detoffol , J Mcnamara . AmJ Orthod Dento facial Orhtop 2006 May. 129 (5) p. .
  24. A polynomial approach to craniofacial growth: description and comparison of adolescent males with normal occlusion and those with untreated Class II malocclusion. P H Buschang , R Tanguay , J Tukeweiz , A Demirjan , La Plame . Am J Orthod DentofacialOrthop 1986. 90 (5) p. .
  25. Longitudinal evaluation of growth changes in Class II division 1 subjects. P W Ngan , Byczeke , J Scheick . SeminOrthod 1997. 3 (4) p. .
  26. The relation of maxillary structure to cranium in malocclusion and in normal occlusion. R A Reidel . Angle Orthod 1952. 22 (3) p. .
  27. Differential diagnosis of Class II malocclusion part 1. Facial types associated with Class II malocclusions. R E Moyers , M L Riolo , K E Guire , R L Wainright , F L Bookstein . Am J Orthod 1980. 78 (5) p. .
  28. Prevalence of malocclusion among Latino adolescents. R G Silva , Kang Ds . Am J Orthod Dentofacialorthod 2001. 119 p. .
  29. Dentofacial maturation of untreated normals. R M Sinclair Pm Little . Am J Orthod 1985. 88 p. .
  30. Changes in dentofacial structures in untreated Class II division 1 and normal subjects: a Longitudinal study. S E Bishara , J R Jakobsen , B Vorhies , P Bayati . Angle Orthod 1997. 67 (1) p. .
  31. Mandibular changes in persons with untreated and treated Class II division 1 malocclusion. S E Bishara . AmJ OrthodDentofacialorthop 1998. 133 (6) p. .
  32. The prevalence of malocclusion amongst Hongkong male dental students. Tang El . Br J Orthod 1994. 21 p. .
  33. Orofacial analysis on the Adriatic islands: An epidemiological study of malocclusion on Hvarisland. T Lauc . Eur J Orthod 2003. 25 p. .
  34. Facial morphology and growth from 10 to 14 years of age in children presenting Class II division 1 malocclusion: a comparative Cephalometric study. T L Rothstein . Am J Orthod 1971. 60 (6) p. .
  35. Variation in Class II malocclusion: Comparison of Mexican mestizos and American white. T Phelan , Buschangph , R G Behrents , A M Wintergerts , R F Ceen , A Hernandez . Am J OrthodDentofacial Orthop 2004. 125 (4) p. .
  36. Cephalometricevaluatiuon of non-growing females with skeletal and dental class II division 1 malocclusion. Turkkaharaman H Sayino . Angle Orthod 2005. 75 p. .
  37. The class II syndrome: differential diagnosis and treatment. V Sassouni . Angle Orthod 1070. 40 (4) p. .
  38. A Classification of skeletal facial types. V Sassouni . Am J Orthod 1969. 55 (2) p. .
  39. Morphology of the adult mandible in Class II division 1 malocclusion and in excellent occlusion. W A Gilmore . AngleOrthod 1950. 20 p. .
