A Study to Find Anatomic Measurement Correlating to Occlusal Vertical Dimension: Comparison in two Ethnic Groups of Nepal

Table of contents

1. Introduction

lossary of Prosthodontic Terms 1 defines the occlusal vertical dimension as the distance between two selected points when the occluding members are in contact and rest vertical dimension as the distance between two selected points when mandible is in physiologic rest position. For a successful denture in terms of esthetics and function correct vertical dimension should be determined. 2 In clinical practice, there exists no universal rule for determining correct vertical dimension at occlusion because of wide range of individual variation. 3 Use of pre-extraction records, 4 maximum biting force, 5 electrymyographic method, 6 and cephalometric radiograph 7 are some of the techniques utilized for determining occlusal vertical dimension. Millet et al. 8 recommended using multiple methods, like physiologic rest position, swallowing, phonetic, esthetics and facial measurements. Distance between soft tissue landmarks of face was significantly correlated to occclusal vertical dimension. 9 Author ? ? ?: Department of Prosthodontics, B. P. Koirala Institute of Health Sciences, Dharan, Nepal. e-mail: [email protected]

The purpose of this study was to evaluate the correlation between facial measurements and occlusal vertical dimension in two ethnic groups of Nepal.

2. II.

3. Materials and Methods

Two hundred subjects between 19 and 46 years (mean age 25 years) were randomly selected from among the students, staffs, patients and relatives of patients visiting the College of Dental Surgery, B. P. Koirala Institute of Health Sciences. They were divided into two groups according to ethnicity, Aryans and Mongoloids. The inclusion criteria were full set of dentition, straight profile on visual examination, absence of malocclusion, no history of orthodontic and prosthodontic treatment. Each subject was instructed to relax the lips and close mouth in centric relation. The occlusal vertical dimension was measured between most prominent part of chin and nose. Other facial measurements measured were the distance between pupil of eye to corner of mouth (rima oris), distance between outer canthus of one eye to inner canthus of other eye, distance between outer canthus to midpoint of external auditory meatus and vertical height of ear. Independent sample t test was performed to test the difference of means of studied parameters in males and females and in Aryans and Mongoloids. Correlation between these facial measurements and occlusal vertical dimension was studied with Pearson's correlation coefficient (r) at the significance level ?0.05 and 95% confidence interval.

4. III.

5. Results

The mean occlusal vertical dimension of studied sample was 64.87±5.21 mm. In Aryans, it was mm and in Mongoloids mm. The tables 1-4 show the results of this study. It was found that males have significantly longer dimension of OVD. The difference of means of rima oris to pupil distance, vertical height of ear, distance between outer canthus of one eye to inner canthus of other eye and eye-ear distance between males and females was not statistically significant. As we compared two ethnicities (Table 3), it was found that OVD and rima oris to pupil distance were significantly longer in Mongoloids whereas eye-ear distance was significantly longer in Aryans than Mongoloids.

The correlation between the facial measurements and occlusal vertical dimension was found statistically significant in both ethnicities (Table 4). However, the correlation between rima oris to pupil distance was stronger than the others. It was also noted that correlation between other facial measurements (eye-ear distance, distance between canthi and vertical height of ear) in Mongoloids was relatively weaker. Overall, rima oris to pupil distance was significantly correlated to occlusal vertical dimension (Table 5) with stronger correlation than other facial measurements. p-value significant at ?0.05 level. Sig.-significant, NS-not significant IV.

6. Discussion

The loss of teeth results in poor appearance of lower third of face. The restoration of correct vertical dimension in those who have lost it should be in harmony with the upper part of face. Prosthodontists have long been seeking for universally accepted method of determining the OVD. There were methods like use of anterior teeth measurements 10 , closest speaking space 11 , swallowing method 12 , patient's neuromuscular perception 13 , cephalometric radiographs 14 , intra-oral and extra-oral anatomic landmarks 15 and measurement of fingers. 16 All of these methods possess some kinds of disadvantages. The present study gave some idea about facial measurement and their use in determining occlusal vertical dimension.

In present study the occlusal vertical dimension was found 65.90±4.31 mm in male and 63.35±6.03 mm in female. These were found to be longer than the findigs of Ladda et al. 16 (61.4±4.2 mm in male and 56.7±3.0 mm in female) and Kulakarni and Kohli 17 (54 to 59 mm in female and 62 to 65 mm in male). The distance between ANS and Me from cephalometric radiograph in Serbian population, was 67.87±5.67 mm in male and 61.51±5.06 mm in female. 7 Similar measurements were observed in Iraqi adult population reported by Al-Hamadany 18 where occlusal vertical dimension in 75 students was 66.74±6.468 mm. The OVD in males was 68.25±6.134 mm and in females, it was 63.99±6.254 mm. These values are consistent to that of current study.

The correlation was statistically significant and positive with rima oris to pupil of eye (r=0.557), followed by distance between outer canthus of one eye to inner canthus of other eye (r=0.449) and eye-ear distance (r=0.395) and vertical height of ear (r=0.378). This is in contrast with the study done by Delic et al. 19 The correlation of eye-ear distance (r=0.8676) was stronger than pupil to rima oris distance (r=0.4357) in their study. Rima-oris to pupil distance was longer than lower facial height by 3 cm in a study done in Phillipinos by Tina-Olaivar et al. 20 The limitations of the study were only two ethnic groups were taken into consideration and the findings cannot be extrapolated to other races. Also, the sample investigations to endorse or refute the findings of present study in this part of world as most of studies are found pertaining to developed countries.

V.

7. Summary

Anthropometric measurements of facial landmarks were recorded for 200 subjects (100 Aryans and 100 Mongoloids) and correlation of facial measurements to occlusal vertical dimension was tested. Within the limitations of this study, we can conclude that the facial measurements are significantly correlated to the occlusal vertical dimension. Findings of this study will be helpful guide in determination of occlusal vertical dimension. size was very small to conclude the findings. The occlusal vertical dimension is not constant and dynamic. Therefore the anthropometric measurement in dentulous subjects can be an adjunct but not accurate for utilizing in edentulous patients. There need to be further

Figure 1. Figure 1 :
1Figure 1 : Measurement of OVD by Boley gauge
Figure 2. Figure 2 :Figure 3 :
23Figure 2 : Measurement of distance from rima oris to pupil of eye
Figure 3. Figure 4 :
4Figure 4 : Measurement of eye-ear distance
Figure 4. Figure 5 :
5Figure 5 : Measurement of vertical height of ear
Figure 5. Table 1 :
1
Character Number Minimum Maximum Mean Std. deviation
Age 200 19 46 25 4.78
OVD 200 48 77 64.87 5.21
RO-Pu 200 52.5 72 64.77 4.65
OC-IC 200 55 77 66.99 3.74
E-E 200 53 82 69.32 4.17
EH 200 48.4 71 60.25 3.75
Figure 6. Table 2 :
2
Parameters Gender N Mean±S.D. p value Remarks
OVD Male Female 120 80 65.90±4.31 63.35±6.03 0.001 Sig.
RO-Pu Male Female 120 80 64.78±4.43 64.77±4.98 0.437 NS
OC-IC Male Female 120 80 67.27±3.40 66.57±4.19 0.053 NS
E-E Male Female 120 80 70.33±3.91 67.83±4.11 0.967 NS
EH Male Female 120 80 60.93±3.75 59.23±3.55 0.421 NS
Note: p-value significant at ?0.05 level. Sig.-significant, NS-not significant
Figure 7. Table 3 :
3
Parameters Ethnicity N Mean±S.D. p value Remarks
OVD Aryan Mongoloids 100 65.86±3.61 100 63.89±6.29 <0.001 Sig.
RO-Pu Aryan Mongoloids 100 66.90±3.56 100 62.65±4.65 0.003 Sig.
OC-IC Aryan Mongoloids 100 67.56±3.45 100 66.42±3.95 0.062 NS
E-E Aryan Mongoloids 100 68.54±3.24 100 70.12±4.81 <0.001 Sig.
EH Aryan Mongoloids 100 60.21±3.75 100 60.29±3.78 0.200 NS
p-value significant at ?0.05 level. Sig.-significant, NS-not significant
Figure 8. Table 4 :
4
Year
Volume XIV Issue VI Version I
( ) J
Aryans Mongoloids
Measurements Pearson's r p-value Significance Pearson's r p-value significance
OVD 1 1
RO-Pu 0.577 <0.001 Sig. 0.466 <0.001 Sig.
OC-IC 0.508 <0.001 Sig. 0.307 0.002 Sig.
E-E 0.498 <0.001 Sig. 0.320 0.001 Sig.
EH 0.471 <0.001 Sig. 0.278 0.005 Sig.
Note: p-value significant at ?0.05 level. Sig.-significant, NS-not significant
Figure 9. Table 4 :
4
Measurements Pearson's r p-value Significance
OVD 1
RO-Pu 0.557 <0.001 Sig.
OC-IC 0.499 <0.001 Sig.
E-E 0.395 <0.001 Sig.
EH 0.378 <0.001 Sig.
1

Appendix A

  1. , Rev Stomatol Chir Maxillofac 2010 Nov-Dec.. 111 (5-6) p. .
  2. Influence of lower lip support on recording of vertical dimension in edentulous patients. A Ekfeldt , S Karlsson . J Oral Rehabil 1992. 19 p. .
  3. Correlation of vertical dimensions of soft tissue facial profiles. A K Al-Hamdany , N H Kassab . Al-Rafidain Dent J 2010. 10 (2) p. .
  4. Correlation of vertical dimensions of soft tissue facial profiles. A K Al-Hamdany , N H Kassab . Al-Rafidain Dent J 2010. 10 (2) p. .
  5. Syllabus of complete dentures. 2 nd ed. C M Heartwell , A O Rahn . Philadelphia: Lea & Febiger 1974. p. .
  6. Vertical dimension in the treatment of edentulous patient, C Millet , A Leterme , C Jeannin , P Jaudoin .
  7. A comparative study of the upper and lower vertical facial measurements of the Filipinos as it is used in the Willis method for determining the vertical dimension of occlusion. E O Tina-Olaivar , O K Olaivar . J Philipp Dent Assoc 1998 Jun-Aug. 50 (1) p. .
  8. Determination of occlusal vertical dimension: a literature review. F Fayz , A Eslami . J Prosthet Dent 1988 Mar. 59 (3) p. .
  9. Cephalometric analysis of the vertical dimension of occlusion. F L Basler , J R Douglas , R S Moulton . J Prosthet Dent 1961. 11 p. .
  10. Cephalometric indicators of the vertical dimension of occlusion. L Strajnic , D Stanisic-Sinobad , D Markovic , L Stojanovic . Coll Antropol 2008. 32 (2) p. .
  11. Pre-extraction records for complete denture fabrication: a literature review. M Bissau . J Prosthet Dent 2004 Jan. 91 (1) p. .
  12. The speaking method in measuring vertical dimension. M M Silverman . J Prosthet Dent 1953 Mar. 3 (2) p. .
  13. Estimation and correlation of individual facial height and total body height. N Kulkarni , M Kohli . J Int Oral Health 2011 Apr. 3 (2) p. .
  14. Vertical relation of occlusion by the patient's neuromuscular perception. R B Lytle . J Prosthet Dent 1964 Jan-Feb. 14 (1) p. .
  15. Intermaxillary relation established by biting power. R H Boos . J Am Dent Assoc 1940. 27 p. .
  16. A new technique to determine vertical dimension of occlusion from anthropometric measurements of finger. R Ladda , A J Bhandari , V O Kasat , G S Angadi . Indian J Dent Res 2013. 24 p. .
  17. Physiologic vertical dimension and centric relation. Tej Shanahan . J Prosthet Dent 1956. 6 p. .
  18. The glossary of prosthodontics terms. J Prosthet Dent 2005 Jul. 94 (1) .
  19. Vertical dimension and its correlation with lip length and interocclusal distance. W W Hurst . J Am Dent Assoc 1962. 64 p. .
  20. Evaluation of craniometric methods for determination of vertical of occlusion. Z Delic , M Simunovic-Soskic , R Perinic-Grzic , S Vukovojac , Z Rajic , T Kuna . Coll Antropol 2000. 1 p. . (suppl. 24)
  21. Comparison of physiologic methods of determination of occlusal vertical dimension in edentulous persons. Z Miljcovic , M Zeljkovic , M Anojcic . Vojnosanit Pregl 2001 Jul-Aug. 58 (4) p. .
